Hydraulic valves

Pressure relief valves DB и DBW Pressure relief valves DB и DBW

Ponar

Product code: 6355

DN 10, 20, 30

G1/2, G1, G1 1/2

maximum working pressure: 350 bar

maximum flow rate: 650 l/min

Pressure relief valve UZPR6 Pressure relief valve UZPR6

Ponar

Product code: 537

DN 6

maximum working pressure: 350 bar

maximum flow rate: 60 l/min

Brake valves FD Brake valves FD

Oleodinamica Mozioni

Product code: 6843

DN 12–32

maximum working pressure: 420 bar

maximum flow rate: 560 l/min

Flow regulator valves DV(P)/DRV(P) Flow regulator valves DV(P)/DRV(P)

Oleodinamica Mozioni

Product code: 6543

DN 6-30

G1/4–G1 1/2

maximum working pressure: 350 bar

maximum flow rate: 600 l/min

Pressure relief valves UZPR10 Pressure relief valves UZPR10

Ponar

Product code: 538

DN 10

maximum working pressure: 350 bar

maximum flow rate: 100 l/min

Pilot operated double check valve type Z2S6 Pilot operated double check valve type Z2S6

Ponar

Product code: 6353

DN 6

maximum working pressure: 350 bar

maximum flow rate: 60 l/min

Pilot operated double check valve type Z2S10 Pilot operated double check valve type Z2S10

Ponar

Product code: 462

DN 10

maximum working pressure: 350 bar

maximum flow rate: 120 l/min

Pilot operated double check valve type Z2S16 Pilot operated double check valve type Z2S16

Ponar

Product code: 463

DN 16

maximum working pressure: 350 bar

maximum flow rate: 200 l/min

Double throttle Z2FS6 with check valve Double throttle Z2FS6 with check valve

Ponar

Product code: 6354

DN 6

maximum working pressure: 350 bar

maximum flow rate: 60 l/min

Double throttle Z2FS10 Double throttle Z2FS10

Ponar

Product code: 480

DN 10

maximum working pressure: 315 bar

maximum flow rate: 80 l/min

Throttle/check valve Z2FS16 Throttle/check valve Z2FS16

Ponar

Product code: 481

DN 16

maximum working pressure: 350 bar

maximum flow rate: 250 l/min

Direct operated pressure relief valve DBD Direct operated pressure relief valve DBD

Ponar

Product code: 525

M28x1.5, M35x1.5, M45x1.5

maximum working pressure: 630 bar

maximum flow rate: 250 l/min

Relief valve VMP Relief valve VMP

Oleodinamica Marchesini

Product code: 644

G3/8, G1/2, G3/4

maximum working pressure: 300 bar

maximum flow rate: 90 l/min

Check valves VU Check valves VU

Oleodinamica Marchesini

Product code: 626

G1/8–G2

maximum working pressure: 350 bar

maximum flow rate: 650 l/min

Double pilot operated check valves VBPDE Double pilot operated check valves VBPDE

Oleodinamica Marchesini

Product code: 583

G1/4–G3/4

maximum working pressure: 350 bar

maximum flow rate: 100 l/min

Flow regulator valves 90 ° VRFB Flow regulator valves 90 ° VRFB

Oleodinamica Marchesini

Product code: 619

G1/4–G1

maximum working pressure: 350 bar

maximum flow rate: 110 l/min

Flow regulator valves VRFU 90 ° with the check valve Flow regulator valves VRFU 90 ° with the check valve

Oleodinamica Marchesini

Product code: 621

G1/4–G1

maximum working pressure: 350 bar

maximum flow rate: 110 l/min

Double acting plough overturning valves VSI42-OWC-DE-38-KIT EVO Double acting plough overturning valves VSI42-OWC-DE-38-KIT EVO

OMT

Product code: 6705

G3/8

maximum working pressure: 350 bar

Single acting Plough overturning valves VRA SE Single acting Plough overturning valves VRA SE

Oleodinamica Marchesini

Product code: 5283

G3/8

maximum working pressure: 400 bar

Single overcentre valves VBCD SE CC Single overcentre valves VBCD SE CC

Oleodinamica Marchesini

Product code: 6552

G3/8, G1/2, G3/4

maximum working pressure: 350 bar

maximum flow rate: 105 l/min

Single overcentre valves VBCD SE A Single overcentre valves VBCD SE A

Oleodinamica Marchesini

Product code: 668

G1/4–G1

maximum working pressure: 350 bar

maximum flow rate: 160 l/min

Single overcentre valves VBCD DE A Single overcentre valves VBCD DE A

Oleodinamica Marchesini

Product code: 661

G1/4–G1

maximum working pressure: 350 bar

maximum flow rate: 160 l/min

Double pilot operated check valve VBPDE A Double pilot operated check valve VBPDE A

Oleodinamica Marchesini

Product code: 586

G1/4–G3/4

maximum working pressure: 350 bar

maximum flow rate: 100 l/min

Double pilot operated check valve VBPDE c /RUB with crane Double pilot operated check valve VBPDE c /RUB with crane

Oleodinamica Marchesini

Product code: 589

G1/4, G3/8, G1/2

maximum working pressure: 350 bar

maximum flow rate: 50 l/min

Hydraulic valves

Principle work of hydraulic valves

Hydraulic valves are hydraulic devices which control the parameters of the fluid flow by changing the flow area of the hydraulic device through the movement of the shut-off-control element under the influence of the fluid flow (directly or indirectly)

Hydraulic valves types:

  • check;
  • relief;
  • reduction;
  • brake valves;
  • discharge valves;
  • chokes;
  • hydraulic locks.

This type of valves are either control valves (regulate the pressure in the fluid flow) or directional valves (stop or let the fluid flow when the flow parameters specified by the valve settings are reached).

Hydraulic valves application

Hydraulic valves are used in case of necessary of the adjustment of the fluid passing through the pipeline. Control valves, for example, are used to adjust fluid pressure. Directional valves allow or block the flow, when it reaches specific parameters of pressure, temperature, speed.

The entire range of hydraulic valves and other hydraulic equipment is presented on our website. You can also choose the necessary hydraulic valves by type of installation: cartridge, modular, tiled (butt), pipe and flange mounting.
